| No. | Component | Model/Type | Technical Specifications |
|---|---|---|---|
| 1 | Light Pole | Q235 Steel | Height: 10m; Diameter: 150*75mm Square tube; 4mm thickness; Hot deep galvanized and powder coating; Working life ≥25 years; Resistance for wind: 45M/S. |
| 2 | Lighting Source | LED Module | 50W*3 Modules; Efficiency: 150 LM/W; Lumen: 22500LM; Protection: IP66 IK:08; LED Chip: Bridgelux/San'an; Working life: ≥80,000 hours; Driver: Moso/Meanwell; DALI dimming. |
| 3 | LED Controller | FT-AUNB-A1-X6.26 | Zigbee/Power carrier; 0-10V dimming; Over-current protection; Lamp condition detection. |
| 4 | Atmospheric Monitoring | 5 in 1 Sensor | PM2.5, Temperature, Humidity, Wind speed, Wind direction. |
| 5 | IP Audio/Broadcast | FT-AUNB-NAS-P3.0 | 30W; Network audio decoding; Dual-core (ARM + DSP) chip; Built-in high fidelity loudspeaker; Standard RJ45 interface. |
| 6 | LED Display | TH-DP-P4LED | P4 Outdoor Full Color; Module size: 256*128mm; Display Size: 896*512mm. |
| 7 | Surveillance Camera | FT-AUNB-HKBQ-PX4.0 | 4 Million pixels, Infrared HD; H.265 compression; 360° continuous rotation; IP66 protection level. |
| 8 | Car Charging Device | Embedded | Output power: 7kW; Efficiency > 99%; Startup via swipe card or APP; Protection level > IP54. |
